C280-8 Marine Propulsion Engine (U.S. EPA Tier 4)

Power Range	3299-3634 bhp (2460-2530 bkW)

Aspiration	TA
Bore	11in
Configuration	In-line 8, 4-Stroke-Cycle Diesel
Displacement	9031in³
Emissions	EPA Tier 4, IMO III
Rotation from Flywheel End	Counterclockwise or clockwise
Speed Range	1000 rpm
Stroke	11.8in

Maximum Height	104in
Maximum Length	195in
Maximum Width	71in
Minimum Dry Weight	41800lb
Minimum Height	104in
Minimum Length	195in
Minimum Width	71in

Standard Equipment:

Aftercooler, fresh water, corrosion resistant coated (air side)
Air inlet shutoff
Breather, crankcase, top-mounted
Turbocharger, engine oil lubricated

Dual Caterpillar A-III Electronic Engine Control Modules with Electronic Unit Injector Fuel System
Rigid Wiring Harness (10 amp 24volt power required to drive Electronic Engine Control Modules)

Engine coolant water drains

Dry, gas tight, exhaust manifold

Distillate fuel (requires viscosity ranging from 1.4 cSt to 20 cSt at 38 degrees C)
Fuel transfer pump (mounted on left hand side)
Duplex fuel filters
Electronically Controlled Unit Injectors

Centrifugal oil filters with single shutoff. Service side engine mounted on cylinder block inspection covers. Includes installed oil lines and single shutoff valve. Filters centrifuge bypass oil from the main lubricating oil pump. Can be serviced with the engine running.
Oil filler and dipstick
Valve, oil pressure regulating
Valves, crankcase explosion relief

Paint, Caterpillar yellow
Pumps, gear driven: fuel, oil, jacket water, aftercooler/oil cooler water

Optional Equipment:

Crankshaft Deflection Marks
Extra Mounting Feet

Auxiliary Drive
Stub Shaft Certification

Air Cleaners

Auxiliary Water Pump
Jacket Water Heaters
Heat Recovery System
Heat Recovery Thermostats
De-Aerator
Connections for Driven Equipment
Cooling System Connection Groups

Outlet Expander
Flexible Exhaust Fittings
Weld Flange

Fuel Priming Pump
Duplex Primary Fuel Strainer
Fuel Systems Connections

Oil Pan Drain Valve
Lube Connections
Lube Oil Heater

Spray Shielding

Monitoring System
ECP Relay System Options
ECP Mechanical Gauge Instrument Panel
Turbocharger Speed Sensor
Cylinder Pressure Relief Valve
Oil Mist Detector
Protection System Components
Wiring
Magnetic Pickup

Intake and Air System
Basic Engine
Cylinder Head
Fuel System
Cooling System
Instrumentation
Cylinder Valve Kits

Boost Control Valve, Pressure Reducing Valve

Basic System Testing
Special Witness Test
Customer Selected Test Points
Marine Limit Line Test
Propeller Demand Curve Test

Commissioning
Service Tools
Shipping Protection - Export Boxing
AID Emblem
Storage Preservation
