| Engine Model | Cat C13 |
|---|---|
| Flywheel Power - Tractor | 407HP |
| Flywheel Power - Tractor/Scraper | 304 kW (407 hp) |
| Note | C13 engine emits equivalent to U.S. EPA Tier 2/EU Stage II or U.S. EPA Tier 3/EU Stage III. |
| Rated Engine RPM | 2000r/min |
| Scraper Capacity - Heaped | 23yd³ |
|---|
| Top Speed - Loaded | 33.5mile/h |
|---|
| Axle to Vertical Hitch Pin | 17in |
|---|---|
| Front of Tractor to Front Axle | 122.8in |
| Ground Clearance - Tractor | 21.9in |
| Height - Overall Shipping | 158.9in |
| Height - Scraper Blade Maximum | 20.5in |
| Height - Top of Cab | 142.6in |
| Height - Top of Elevator | 148.3in |
| Length - Overall Machine | 542in |
| Rear Axle - Rear of Machine | 89.7in |
| Wheel Base | 329.5in |
| Width - Inside of Bowl | 120in |
| Width - Outside Rear Tires | 128.9in |
| Width - Overall Machine | 141.1in |
| Width - Overall Machine - Ladder Down | 149.2in |
| Width - Rear Tire Centers | 90.2in |
| Width - Tractor | 133.1in |
| Cooling System | 11.89gal (US) |
|---|---|
| Crankcase | 8.08gal (US) |
| Fuel Tank | 216.09gal (US) |
| Hydraulic System | 21.926gal (US) |
| Transmission System | 24.76gal (US) |
| 180° Curb-to-Curb Turning Width | 38.71ft |
|---|---|
| Elevator Flight Spacing | 20in |
| Fuel Tank Refill Capacity - Scraper | 201gal (US) |
| Maximum Depth of Cut | 10.3in |
| Maximum Depth of Spread | 18.3in |
| Maximum Floor Opening | 4.4ft |
| Number of Flights | 15 |
| Operating Weight - Empty | 88061lb |
| Overall Length | 45.18ft |
| Overall Shipping Height | 12.37ft |
| Overall Width | 11.71ft |
| Rated Load | 25 038 kg (55,200 lb); 25.1 tonnes (27.6 tons) |
| Scraper Capacity - Heaped | 23yd³ |
| Scraper Capacity - Struck | 18.8yd³ |
| Tires - Scraper | 33.25R29**E3 |
| Tires - Tractor Drive | 33.25R29**E3 |
| Top Speed - Loaded | 33.5mile/h |
| Width - Cut | 10.3ft |
| Exterior Sound Level | The exterior sound power level for the standard machine (ISO 6393) is 111.5 dB(A). |
|---|---|
| ROPS/FOPS | Meets ISO standards |
| Brakes | ISO 3450:2011 |
|---|---|
| Falling Object Protective Structure (FOPS) | ISO 3449:2005 Level II |
| Reverse Alarm | ISO 9533:2010 |
| Rollover Protection Structure (ROPS) | ISO 3471:2008 for up to 17 084 kg (37,664 lb) |
| Seat Belt | SAE J386:JUN1985 |
| Steering System | ISO 5010:2007 |
| Transmission Gear - Eighth | 33.5mile/h |
|---|---|
| Transmission Gear - Fifth | 13.6mile/h |
| Transmission Gear - First | 3.1mile/h |
| Transmission Gear - Fourth | 10.1mile/h |
| Transmission Gear - Reverse | 5.7mile/h |
| Transmission Gear - Second | 5.5mile/h |
| Transmission Gear - Seventh | 24.8mile/h |
| Transmission Gear - Sixth | 18.4mile/h |
| Transmission Gear - Third | 7.5mile/h |
| Bowl Lower | 3.5s |
|---|---|
| Bowl Raise | 3s |
| Ejector Extend | 6.45s |
| Ejector Retract | 9.7s |
