| Displacement | 428in³ |
|---|---|
| Emissions | Tier 4/Stage IV |
| Engine Model | Cat C7.1 |
| Maximum Net Power - 2,100 rpm - ISO 9249 | 250HP |
| Maximum Net Power - 2,100 rpm - ISO 9249 - Metric | 253HP |
| Maximum Net Power - 2,100 rpm - SAE J1349 | 250HP |
| Maximum Net Torque - 1,350 rpm | 865ft·lbf |
| Maximum Power - 2,100 rpm - ISO 14396 | 269HP |
| Maximum Power - 2,100 rpm - ISO 14396 - Metric | 273HP |
| Maximum Power - 2,100 rpm - SAE J1995 | 271HP |
| Net Power - ISO 9249 | 250HP |
| Note | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes. |
| Peak Gross Torque - 1,350 rpm - ISO 14396 | 918ft·lbf |
| Peak Gross Torque - 1,350 rpm - SAE J1995 | 921ft·lbf |
| Note | Weight based on a machine configuration with Michelin 23.5R25 XHA2 L3 radial tires, full fluids, operator, standard counterweight, cold start, roading fenders, Product Link™, manual diff lock/open axles (front/rear), power train guard, secondary steering, |
|---|---|
| Operating Weight | 44591lb |
| Bucket Capacities | 2.5-9.2 m³ (3.3-12.0 yd³) |
|---|
| Centerline of Rear Axle to Edge of Counterweight | 7.08ft |
|---|---|
| Centerline of Rear Axle to Hitch | 5.5ft |
| Ground Clearance | 1.17ft |
| Height - Top of Exhaust Pipe | 11.17ft |
| Height - Top of Hood | 8.83ft |
| Height - Top of ROPS | 11.33ft |
| Hinge Pin Height at Carry Height | 2.58ft |
| Hinge Pin Height at Maximum Lift | 14.83ft |
| Lift Arm Clearance at Maximum Lift | 11.83ft |
| Maximum Width - Over Tires - Loaded | 9.25ft |
| Note | All dimensions are approximate and based on Michelin 23.5R25 XHA2 L3 radial tires. |
| Overall Length - Without Bucket | 23.75ft |
| Rack Back - Carry Height | 49 degrees |
| Rack Back - Maximum Lift | 59 degrees |
| Rack Back at Ground | 37 degrees |
| Tread Width | 7ft |
| Wheel Base | 11ft |
| Hydraulic Cycle Time - Total | 8.9s |
|---|---|
| Implement Pump Type | Variable Axial Piston |
| Implement System - Maximum Operating Pressure | 4250psi |
| Implement System - Maximum Pump Output at 2,150 rpm | 76gal/min |
| Centerline of Rear Axle to Edge of Counterweight | 7.08ft |
|---|---|
| Centerline of Rear Axle to Hitch | 5.5ft |
| Ground Clearance | 1.17ft |
| Height - Top of Exhaust Pipe | 11.17ft |
| Height - Top of Hood | 8.83ft |
| Height - Top of ROPS | 11.33ft |
| Hinge Pin Height at Carry Height | 2.17ft |
| Hinge Pin Height at Maximum Lift | 13.92ft |
| Lift Arm Clearance at Maximum Lift | 11.33ft |
| Maximum Width - Over Tires - Loaded | 9.25ft |
| Note | All dimensions are approximate and based on Michelin 23.5R25 XHA2 L3 radial tires. |
| Overall Length - Without Bucket | 23.75ft |
| Rack Back - Carry Height | 49 degrees |
| Rack Back - Maximum Lift | 59 degrees |
| Rack Back at Ground | 37 degrees |
| Tread Width | 7ft |
| Wheel Base | 11ft |
| Crankcase | 5.8gal (US) |
|---|---|
| DEF Tank | 4.2gal (US) |
| Differential - Final Drives - Front | 11.4gal (US) |
| Differential - Final Drives - Rear | 11.4gal (US) |
| Fuel Tank | 72.6gal (US) |
| Hydraulic Tank | 33gal (US) |
| Forward - 1 | 4.3mile/h |
|---|---|
| Forward - 2 | 7.5mile/h |
| Forward - 3 | 12mile/h |
| Forward - 4 | 16mile/h |
| Forward - 5 | 24.5mile/h |
| Note | Maximum travel speed in standard vehicle with empty bucket and standard L3 tires with 787 mm (31 in) roll radius. |
| Reverse - 1 | 4.3mile/h |
| Reverse - 2 | 7.5mile/h |
| Reverse - 3 | 16mile/h |
| Note (1) | *Distance of 15 m (49.2 ft), moving forward in second gear ratio. |
|---|---|
| Note (2) | **For machines in European Union countries and in countries that adopt the EU Directives. |
| Note (3) | ***European Union Directive 2000/14/EC as amended by 2005/88/EC. |
| With Cooling Fan Speed at 70% of Maximum Value - Exterior Sound Power Level (ISO 6395:2008)** | 104 LWA*** |
| With Cooling Fan Speed at 70% of Maximum Value - Operator Sound Pressure Level (ISO 6396:2008)** | 69dB(A) |
| With Cooling Fan Speed at Maximum Value - Exterior Sound Power Level (ISO 6395:2008) | 107dB(A) |
| With Cooling Fan Speed at Maximum Value - Exterior Sound Pressure Level (SAE J88:2013) | 75 dB(A)* |
| With Cooling Fan Speed at Maximum Value - Operator Sound Pressure Level (ISO 6396:2008) | 70dB(A) |
| Breakout Force | 42489lbf |
|---|---|
| Note (1) | For a machine configuration as defined under Weight. |
| Note (2) | Full compliance to ISO 143971:2007 Sections 1 thru 6, which requires 2% verification between calculations and testing. |
| Static Tipping Load - Full 40° Turn - No Tire Deflection | 27494lb |
| Static Tipping Load - Full 40° Turn - With Tire Deflection | 25814lb |
| Centerline of Rear Axle to Edge of Counterweight | 85in |
|---|---|
| Centerline of Rear Axle to Hitch | 66in |
| Ground Clearance | 14in |
| Height - Top of Exhaust Pipe | 134in |
| Height - Top of Hood | 106in |
| Height - Top of ROPS | 136in |
| Hinge Pin Height at Carry Height | 26in |
| Hinge Pin Height at Maximum Lift | 167in |
| Lift Arm Clearance at Maximum Lift | 136in |
| Maximum Width over Tires (loaded) | 111in |
| Note | All dimensions are approximate and based on Michelin 23.5R25 XHA2 L3 radial tires. |
| Overall Length (without bucket) | 285in |
| Tread Width | 84in |
| Wheel Base | 132in |
| Bucket Range | 2.5-9.2 m³ (3.3-12.0 yd³) |
|---|
| Emissions | Tier 4/Stage IV |
|---|
