| Biodiesel Capability | Up to B20¹ |
|---|---|
| Bore | 4.1in |
| Displacement | 268.5in³ |
| Emissions | Meets U.S. EPA Tier 4 Final, EU Stage V, Japan 2014 emission standards. |
| Engine Model | C4.4 |
| Engine Power - ISO 14396 (DIN) | 150hp (metric) |
| Engine Power - ISO 14396:2002 | 148hp |
| Net Power - ISO 9249 | 145hp |
| Net Power - ISO 9249 (DIN) | 147hp (metric) |
| Note (1) | Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, CEM exhaust gas aftertreatment, alternator, and cooling fan with engine speed at 2,200 rpm. Advertised power is tested per the specified standar |
| Note (2) | ¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO |
| Stroke | 127mm |
| Operating Weight Maximum | 39680lb |
|---|---|
| Operating Weight Minimum | 34610lb |
| Creeper Speed - 1st Gear | 3.4mile/h |
|---|---|
| Creeper Speed - 2nd Gear | 9.3mile/h |
| Drawbar Pull | 23380lbf |
| Forward/Reverse - 1st Gear | 6.2mile/h |
| Forward/Reverse - 2nd Gear | 21.7mile/h |
| Maximum Travel Speed | 21.7mile/h |
| Main System - Maximum Flow - Implement | 73gal/min |
|---|---|
| Maximum Pressure - Implement Circuit - Heavy Lift | 5366psi |
| Maximum Pressure - Implement Circuit - Normal | 5076psi |
| Maximum Pressure - Implement Circuit - Travel Circuit | 5076psi |
| Maximum Swing Torque | 30340ft·lbf |
|---|---|
| Swing Speed | 9.1r/min |
| Cooling System | 24l |
|---|---|
| Diesel Exhaust Fluid (DEF) | 5.3gal (US) |
| Fuel Tank | 74gal (US) |
| Hydraulic System - Including Tank | 58.1gal (US) |
| Hydraulic Tank | 23.8gal (US) |
| Boom | VA 5.2 m (17'1") |
|---|---|
| Bucket | GD 0.76 m³ (0.99 yd³ ) |
| Counterweight Clearance | 4.2ft |
| Ground Clearance | 1.5ft |
| Shipping Height - Top of Cab | 10.9ft |
| Shipping Length | 25.1ft |
| Stick | 2.5m (8'2") |
| Support Point | 10.1ft |
| Tail Swing Radius | 5.9ft |
| Undercarriage Length | 16ft |
| Wheel Base | 8.4ft |
| Boom Type | VA 5.2 m (17'1") |
|---|---|
| Bucket | GD 0.76 m³ (0.99 yd³ ) |
| Bucket Forces (ISO) | 23830lbf |
| Cutting Height | 34.2ft |
| Digging Height | 18.4ft |
| Dump Height | 25.2ft |
| Reach at Ground Level | 29.6ft |
| Stick | 2.5m (8'2") |
| Stick Forces (ISO) | 15961lbf |
| Vertical Wall Digging Depth | 15ft |
| Note | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.8 kg of refrigerant which has a CO2 equivalent of 1.144 metric tonnes. |
|---|
