| Note (1) | Operating weights are approximate and consider full fluids and 75 kg (165 lb) operator. Cab weights include heat and air conditioning. |
|---|---|
| Operating Weight - With Cab | 27900lb |
| Operating Weight - With ROPS/FOPS Canopy | 27560lb |
| Weight - Drum with Cab | 17051lb |
| Weight - Drum with ROPS/FOPS Canopy | 16955lb |
| Compaction Width | 84in |
|---|---|
| Drum Diameter | 60.4in |
| Maximum Height | 9.9ft |
| Overall Length | 18.7ft |
| Overall Width | 7.5ft |
| Wheel Base | 9.8ft |
| Bore | 3.9in |
|---|---|
| Emissions | U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V |
| Engine Model | Cat® C3.6 |
| Engine Power - ISO 14396 | 121hp |
| Gross Power | 122.9hp |
| Net Power - ISO 9249 | 112.2hp |
| Net Power - SAE J1349:2011 | 111.2hp |
| Note (1) | Net power advertised is the power available at the engine flywheel when equipped with a fan at maximum speed, air cleaner, clean emissions module, and alternator. |
| Stroke | 4.7in |
| Curb Clearance | 19.4in |
|---|---|
| Ground Clearance | 20.4in |
| Travel Speed - Maximum | 6.8mile/h |
| Turning Radius - Inside Drum Edge | 12.7ft |
| Axle and Final Drives | 2.6gal (US) |
|---|---|
| Cooling System | 4.9gal (US) |
| DEF Tank | 5gal (US) |
| Eccentric Weight Housings (combined) | 6.9gal (US) |
| Engine Oil - With Filter | 3.1gal (US) |
| Fuel Tank Capacity | 56.3gal (US) |
| Hydraulic Tank | 6.1gal (US) |
| Recyclability | 95% |
|---|
| Centrifugal Force - Maximum | 56200lb |
|---|---|
| Centrifugal Force - Minimum | 33500lb |
| Nominal Amplitude - High | 0.079in |
| Nominal Amplitude - Low | 0.039in |
| Static Linear Load - With Cab | 202.9lb/in |
| Static Linear Load - With ROPS/FOPS Canopy | 201.8lb/in |
