| Note (1) | Operating weights are approximate and consider full fluids and 80 kg (176 lb) operator. Cab weights include heat and air conditioning. |
|---|---|
| Operating Weight - With Cab | 26266lb |
| Operating Weight - With ROPS/FOPS Canopy | 25823lb |
| Weight - Drum with Cab | 14235lb |
| Weight - Drum with ROPS/FOPS Canopy | 14030lb |
| Compaction Width | 84in |
|---|---|
| Drum Diameter - Over Pads | 61in |
| Maximum Height | 10.3ft |
| Optional Blade Height | 26.9in |
| Overall Length | 19.2ft |
| Overall Length - With Blade Option | 21ft |
| Overall Width | 7.5ft |
| Overall Width - With Blade Option | 8.2ft |
| Wheel Base | 9.5ft |
| Bore | 4.1in |
|---|---|
| Emissions | U.S. EPA Tier 4 Final |
| Engine Model | Cat® C4.4 |
| Engine Power - ISO 14396 | 156.9hp |
| Gross Power | 159hp |
| Net Power - ISO 9249 | 131.6hp |
| Net Power - SAE J1349:2011 | 129.9hp |
| Note (1) | Net power advertised is the power available at the engine flywheel when equipped with a fan at maximum speed, air cleaner, clean emissions module, and alternator. |
| Stroke | 5in |
| Centrifugal Force - Maximum | 67653lb |
|---|---|
| Centrifugal Force - Minimum | 31680lb |
| Nominal Amplitude - High | 0.083in |
| Nominal Amplitude - Low | 0.039in |
| Variable Frequency Option Range | 23.3 - 30.5 Hz (1400-1830 vpm) |
| Vibratory Frequency - Standard | 1830VPM |
| Curb Clearance | 19.9in |
|---|---|
| Ground Clearance | 17.5in |
| Travel Speed - Maximum | 7.1mile/h |
| Turning Radius - Inside Drum Edge | 12.1ft |
| Axle and Final Drives | 4.8gal (US) |
|---|---|
| Cooling System | 8.3gal (US) |
| DEF Tank | 5gal (US) |
| Eccentric Weight Housings (combined) | 6.9gal (US) |
| Engine Oil - With Filter | 3.1gal (US) |
| Fuel Tank Capacity | 69.7gal (US) |
| Hydraulic Tank | 13.2gal (US) |
| Recyclability | 98% |
|---|
