| Engine Model | Cat C4.4 with ACERT |
|---|---|
| Gross Power | 173HP |
| Hopper Capacity | 250ft³ |
|---|---|
| Inside Turn Radius | 1.5ft |
| Maximum Paving Speed - With Tamper Bar Screed | 82ft/min |
| Maximum Paving Speed - With Vibratory Screed | 210ft/min |
| Maximum Paving Width - SE50 V | 21.3ft |
| Maximum Paving Width - SE50 VT | 26.3ft |
| Maximum Paving Width - SE60 V | 25ft |
| Maximum Paving Width - SE60 V XW, SE60 VT XW | 33ft |
| Maximum Throughput Capacity | 1433tonnes/hr |
| Maximum Travel Speed | 9mile/h |
| Standard Paving Range - SE50 V, SE50 VT | 2.55 - 5.0 m (8' 4" - 16' 4") |
| Standard Paving Range - SE60 V, SE60 V XW, SE60 VT XW | 3.0 - 6.0 m (9' 10" - 19' 6") |
| Operating Weight - Paver Only | 34356lb |
|---|---|
| Operating Weight - SE50 V Screed only | 7239lb |
| Operating Weight - SE50 VT Screed only | 7363lb |
| Operating Weight - SE60 V Screed only | 7495lb |
| Operating Weight - SE60 V XW Screed only | 8973lb |
| Operating Weight - SE60 VT XW Screed only | 9898lb |
| Shipping Weight - Paver Only | 34725lb |
| DEF Tank | 5gal (US) |
|---|---|
| Fuel Tank Capacity | 73gal (US) |
