| Bore | 5.4in |
|---|---|
| Displacement | 1648in³ |
| Emissions | U.S. EPA Tier 4 Final |
| Engine Model | Cat® C27 |
| Engine Power - Gross SAE J1995* (FWD/REV) | 471/571 kW (632/766 HP) |
| Engine Power - ISO 14396 (FWD/REV) | 462/562 kW (620/754 HP) |
| Engine Power - Net SAE J1349/ISO 9249 (FWD/REV) | 447/538 kW (600/722 HP) |
| Engine Power - Net SAE J1349/ISO 9249 DIN (FWD/REV) | 608/732 mhp |
| Flywheel Power | 600HP |
| Net SAE J1349/ISO 9249 (FWD/REV) | 447/538 kW (600/722 HP) |
| Net SAE J1349/ISO 9249 DIN (FWD/REV) | 608/732 mhp |
| Note (1) | *Excludes all fan losses. |
| Note (2) | Engine ratings apply at 1,800 rpm. |
| Note (3) | Net power advertised is the power available at the flywheel when the engine is equipped with air cleaner, muffler, alternator, fan, and engine emissions controls as required. |
| Note (4) | No derating (in FWD gears) required up to 4572 m (15,000 ft) altitude. |
| Stroke | 6in |
| Note (1) | D10T2 Operating Weight includes coolant, lubricants, full fuel tank, ROPS, FOPS cab, SU ABR bulldozer, dual tilt, single-shank ripper with pin-puller, fast fuel, 610 mm/24 in ES shoes, and operator. |
|---|---|
| Note (2) | D10T2 Shipping Weight includes coolant, lubricants, 10% fuel, FOPS cab, fast fuel, and 610 mm/24 in ES shoes. |
| Operating Weight | 154700lb |
| Shipping Weight | 109775lb |
| Ground Clearance | 28.5in |
|---|---|
| Ground Contact Area | 7347in² |
| Grouser Height | 3.7in |
| Length - Track on Ground | 152.8in |
| Number of Carrier Rollers | 1 per side (optional) |
| Pitch | 10.25in |
| Shoe Type | Extreme Service (ES) |
| Shoes/Side | 44 |
| Track Gauge | 100.4in |
| Track Rollers/Side | 8 |
| Width - Shoe | 24in |
| 1 Forward | 2.5mile/h |
|---|---|
| 1 Reverse | 3.2mile/h |
| 2 Forward | 4.5mile/h |
| 2 Reverse | 5.6mile/h |
| 3 Forward | 7.9mile/h |
| 3 Reverse | 9.8mile/h |
| Transmission Clutch Diameter | 17.1in |
| Type | 3-speed planetary powershift |
| Cooling System | 47.6gal (US) |
|---|---|
| Engine Crankcase* | 18gal (US) |
| Final Drive - Each | 6.1gal (US) |
| Fuel Tank | 314.4gal (US) |
| Hydraulic Tank | 34.6gal (US) |
| Note | *With oil filters. |
| Pivot Shaft Compartment | 8.7gal (US) |
| Power Train | 60.8gal (US) |
| Roller Frames - Each | 16.9gal (US) |
| Bulldozer Relief Valve Setting | 4061psi |
|---|---|
| Combined Pump Output - Implement | 100.4gal/min |
| Note (1) | Pump output measured at 1,800 rpm engine speed. |
| Note (2) | Electro-hydraulic pilot valves assist operations of ripper and dozer controls. |
| Note (3) | Complete system consists of pump, tank with filter, oil cooler, valves, lines, and control levers. |
| Pump Type | Variable displacement piston |
| Ripper - Lift - Relief Valve Setting | 4061psi |
| Ripper - Pitch - Relief Valve Setting | 4061psi |
| Tilt Cylinder Relief Valve Setting | 2944psi |
| Drawbar Height (Center of Clevis) | 34in |
|---|---|
| Ground Clearance* | 28.5in |
| Height - FOPS Cab* | 161.3in |
| Height - ROPS/Canopy* | 173.5in |
| Height - Top of Stack* | 171.5in |
| Length - Basic Tractor - With Drawbar | 220.4in |
| Length - Track on Ground | 152.8in |
| Length - With Multi-Shank Ripper | 285.1in |
| Length - With SU-Blade | 292in |
| Length - With Single-Shank Ripper | 278.8in |
| Length - With U-Blade | 305.1in |
| Overall Length - Basic Tractor | 209.6in |
| Overall Length - SU-Blade/SS Ripper | 360.6in |
| Track Gauge | 100.4in |
| Width - Over Trunnions | 147.1in |
| Width - Without Trunnions - 610 mm/24 in ES | 129.6in |
| Hydraulically Applied Multiple-disc Steering Clutch | 15.4in |
|---|---|
| Spring Applied Multiple-disc Brake | 15.4in |
| FOPS | Falling Objects Protective Structure (FOPS) meets the following criteria: ISO 3449:2005 LEVEL II. |
|---|---|
| ROPS | Rollover Protective Structure (ROPS) meets the following criteria: ISO 3471:2008. |
| Sound (1) | The exterior sound pressure level for the standard machine (ISO 6395) is 115 dB(A)/111 dB(A) (sound suppressed). |
| Sound (2) | The operator equivalent sound pressure level (ISO 6396) is 77 dB(A)/74 dB(A) (sound suppressed). |
| Air Conditioning | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.9 kg (4.2 lb) of refrigerant which has a CO2 equivalent of 2.717 metric tonnes (3.0 tons). |
|---|
| Oscillation | 13.8in |
|---|
