| Biodiesel Capability | B20¹ |
|---|---|
| Bore | 4in |
| Displacement | 269in³ |
| Emissions | Meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards. |
| Engine Model | Cat C4.4 |
| Engine Power - ISO 14396 | 173hp |
| Engine Power - ISO 14396 (DIN) | 175hp (metric) |
| Net Power - ISO 9249 | 170hp |
| Net Power - ISO 9249 (DIN) | 173hp (metric) |
| Note (1) | Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 2,200 rpm. Advertised power is tested per the specified standard in effect at time of |
| Note (2) | ¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO |
| Stroke | 5in |
| Maximum Drawbar Pull | 45187lbf |
|---|---|
| Maximum Travel Speed | 3.5mile/h |
| Main System - Maximum Flow | 113gal/min |
|---|---|
| Maximum Pressure - Equipment | 5076psi |
| Maximum Pressure - Equipment - Lift Mode | 5511psi |
| Maximum Pressure - Swing | 3989psi |
| Maximum Pressure - Travel | 5076psi |
| Maximum Swing Torque | 60480lbf·ft |
|---|---|
| Swing Speed | 11r/min |
| Forestry Road Builder | 62170lb |
|---|---|
| General Forestry | 59700lb |
| Log Loader (MH Stick) | 63050lb |
| Log Loader (U/U) | 63300lb |
| Note (1) | High long undercarriage (High LC), 165 mm (6.5") fixed riser side entry cab (SEC) 5.7 m (18'7") reach boom, R3.7 m (12’2”) drop nose stick, 700 mm (28”) double grouser (DG) shoes, no processor head |
| Note (2) | High LC, 1219 mm (48") tilting riser SEC, 5.9 m (19’6”) straight boom, 3.5m (11'6") u/u stick with live heel, 700mm (28") double grouser (DG) shoes, no grapple |
| Note (3) | High LC, 165 mm (6.5”) fixed riser SEC, 5.7 m (18'7") reach boom, R2.9 (9'7") thumb ready stick, 700mm (28") double grouser shoes, 1.2 m³ (1.6 yd³) HD bucket. |
| Note (4) | High LC, 1219 mm (48") tilting riser SEC, 5.9 m (19’6”) Straight boom, 5.8 m (19') drop nose log loader stick, 700mm (28") double grouser shoes, no grapple |
| Cooling System | 6.6gal (US) |
|---|---|
| DEF Tank | 6.9gal (US) |
| Engine Oil | 4gal (US) |
| Final Drive - Each | 1.3gal (US) |
| Fuel Tank | 91.1gal (US) |
| Hydraulic System - Including Tank | 65.6gal (US) |
| Hydraulic Tank | 34.1gal (US) |
| Swing Drive | 1.3gal (US) |
| Counterweight Clearance | 3.4ft |
|---|---|
| Ground Clearance for High Undercarriage | 2ft |
| Ground Clearance for Standard Undercarriage | 1.4ft |
| Handrail Height | 9.8ft |
| Length: General Forestry - Boom Stretched Out | 38.3ft |
| Length: Log Loader - Boom Stretched Out | 44.1ft |
| Note (1) | General Forestry configuration with High LC, SEC with 165 mm (6.5") fixed riser, 5.7 m (18'7") Reach boom, 2.8 m (9'7") Thumb ready stick, 700 mm (28") double grouser (DG) shoes |
| Shipping Height - Tilted Cab | 11.3ft |
| Tail Swing Radius | 9.3ft |
| Track Gauge | 7.8ft |
| Track Length | 14.7ft |
| Track Length to Center of Rollers | 11.9ft |
| Transport Width | 11ft |
| Max Reach at Grapple Mount on Heel at Ground Level - Log Loader Under/Under | 36ft |
|---|---|
| Max Reach at Stick Nose at Ground Level - General Forestry Processor | 29.1ft |
| Max Reach at Stick Nose at Ground Level - General Forestry Road Builder | 32.3ft |
| Max Reach at Stick Nose at Ground Level – Log Loader MH Stick | 38.1ft |
| Note (1) | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.1 (22" Riser CAB)/2.2 (48"/72" Riser CAB) kg of refrigerant, which as a CO2 equivalent of 3.003/ |
|---|
