| Biodiesel Capability | B20¹ |
|---|---|
| Bore | 6in |
| Displacement | 1105in³ |
| Emissions | Meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, and Japan 2014 emission standards. |
| Engine Model | Cat C18 |
| Engine Power - ISO 14396 | 543hp |
| Engine Power - ISO 14396 (DIN) | 551hp (metric) |
| Net Power - ISO 9249 | 542hp |
| Net Power - ISO 9249 (DIN) | 550hp (metric) |
| Note (1) | Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system and alternator with engine speed at 1,900 rpm. Advertised power is tested per the specified standard in effect at time of m |
| Note (2) | ¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO |
| Stroke | 7in |
| Note (1) | Standard variable gauge undercarriage, 4.6 m (15ft 9in) Front Shovel (FS) Boom, 3.48 m (11ft 42in) FS Stick, FS 6.5m³ (8.5 yd³) bucket, 650 mm (26in) double grouser shoes, 15,450 kg (34,060 lb) counterweight |
|---|---|
| Operating Weight | 212300lb |
| Boom | Front Shovel (FS) Boom 4.6m (15"9') |
|---|---|
| Bucket | Front Shovel (FS) 6.5m³ (8.5 yd³) |
| Bucket Digging Force - ISO | 115550lbf·ft |
| Maximum Cutting Height | 9.7ft |
| Maximum Depth Cut for 2440 mm (8 ft) Level Bottom | 23.1ft |
| Maximum Digging Depth | 9.7ft |
| Maximum Loading Height | 37.4ft |
| Maximum Reach at Ground Level | 32.1ft |
| Maximum Vertical Wall Digging Depth | 12.1ft |
| Minimum Loading Height | 34.4ft |
| Stick | Front Shovel (FS) Stick 3.48m (11'42") |
| Stick Digging Force - ISO | 106560lbf·ft |
| Main System - Maximum Flow - Implement | 266gal/min |
|---|---|
| Maximum Pressure - Equipment | 4641psi |
| Maximum Pressure - Swing | 4496psi |
| Maximum Pressure - Travel | 5076psi |
| Maximum Swing Torque | 267000lbf·ft |
|---|---|
| Note (1) | *For CE-marked machine default value may be set lower |
| Cooling System | 19gal (US) |
|---|---|
| DEF Tank | 21gal (US) |
| Engine Oil | 18gal (US) |
| Final Drive - Each | 5.3gal (US) |
| Fuel Tank Capacity | 322gal (US) |
| Hydraulic System - Including Tank | 196gal (US) |
| Hydraulic Tank | 114gal (US) |
| Swing Drive | 3.2gal (US) |
| Boom | Front Shovel (FS) Boom 4.6m (15"9') |
|---|---|
| Bucket | Front Shovel (FS) 6.5m³ (8.5 yd³) |
| Counterweight Clearance | 5.5ft |
| Ground Clearance | 2.11ft |
| Handrail Height | 11.1ft |
| Note | Track gauge undercarriage extended with 650 mm (26") shoes; transport width undercarriage retracted with 650 mm (26") shoes and no steps |
| Shipping Height - Top of Cab | 14.1ft |
| Shipping Length | 48ft |
| Stick | Front Shovel (FS) Stick 3.48m (11'42") |
| Tail Swing Radius | 15.11ft |
| Track Gauge | 11.6ft |
| Track Length | 19.2ft |
| Track Length to Center of Rollers | 15.1ft |
| Transport Width | 9ft |
| Recyclability | 98% |
|---|
| Air Conditioning | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.00 kg (2.2lb) of refrigerant, which has a CO2 equivalent of 1.430 metric tonnes (1.576 tons). |
|---|
