| Bit Speed at Maximum Flow | 127 rpm |
|---|---|
| Drive Method | Gerotor Motor - Direct Drive |
| Drive Shaft Torque at Maximum Pressure | 1699.3lb/ft |
| Hex Output Shaft Size | 2in |
| Housing Diameter | 11in |
| Motor Displacement | 38in³ |
| Mounting Bracket Design | 2 Ton Mini Excavator Pin On |
| Optimal Hydraulic Flow | 42-83 L/min (11-22 gpm) |
| Optimal Hydraulic Pressure | 145-235 bar (2100-3400 psi) |
| Overall Height | 37.3in |
| Overall Length - With Bracket | 11.1in |
| Overall Width - With Bracket | 11.1in |
| Required Hydraulics | Standard Flow |
| Swing Range (L/R) | 76 degrees |
| Swing Range (fore/aft) | 70 degrees |
| Weight | 257.9lb |
