Medical Open Scroll Systems

Modelo	Sistema HP	Bomba HP	SCFM @ 50 PSIG	Depósito (gal)	dB(A) Nivel	FLA @ 208V	FLA @ 230V	FLA @ 460V
Tankmount Systems
MTSD0303	3 (2)	3	9.5	80	66	19.1	17.4	9.7
MTSD0503	5 (2)	5	16.6	80	70	30.0	27.4	14.7
Sistemas dúplex
MSD02A3	2 (2)	2	6	80	62	14.4	13.3	7.9
MSD03A3	3 (2)	3	9.5	80	66	19.2	17.4	9.7
MSD05A3	5 (2)	5	16.6	80	70	30	27.4	14.7
MSD0754	7.5 (2)	7.5	23.8	120	74	40.4	36.6	19.3
MSD10B4	10 (2)	10	31.6	120	76	55	50	26
MSD10A4	10 (2)	5	33.2	120	82	170	154.4	78
MSD10A5	10 (2)	5	33.2	200	76	55	50	26
MSD10A6	10 (2)	5	33.2	240	76	55	50	26
MSD15B4	15 (2)	7.5	47.6	120	77	79	71	37
MSD15A4	15 (2)	5	49.8	120	78	86	78.2	40
MSD15A5	15 (2)	5	49.8	200	78	86	78.2	40
MSD15A6	15 (2)	5	49.8	240	78	86	78.2	40
MSET30B6	20 (2)	10	63.2	120	79	108	98	50
Duplex Systems Expandable To Triplex
MSD05A3-EX3	5 (2) / 5 (3)	5	16.6	80	75	44	40.1	21
MSD05A4-EX4	5 (2) / 5 (4)	5	33.2	120	77	58	52.8	27.3
MSD0754-EX3	7.5 (2) / 7.5 (3)	7.5	23.8	120	74	40	37	19
MSD10A5-EX3	10 (2) / 10 (3)	5	33.2	200	78	86	78.2	40
MSD10B5-EX3	10 (2) / 10 (3)	10	31.6	200	76	55	50	26
MSD15A4-EX3	15 (2) / 15 (3)	5	49.8	120	80	128	116.3	59
MSD15A5-EX3	15 (2) - 15 (3)	5	49.8	200	80	128	116.3	59
MSD15A6-EX3	15 (2) / 15 (3)	5	49.8	240	80	128	116.3	59
MSD15B5-EX3	15 (2) / 15 (3)	7.5	47.6	200	77	79	71	37
Sistemas Triplex
MST03A3	3 (3)	3	19	80	72	27.9	25.4	13.7
MST05A3	5 (3)	5	33.2	80	75	44	40.1	21
MST05A4	5 (3)	5	33.2	120	75	44	40.1	21
MST0755	7.5 (3)	7.5	47.6	200	77	59.6	53.9	28
MST10B5	10 (3)	10	63.2	200	79	81.5	74	38
MST10A4	10 (3)	5	66.4	120	78	86	78.2	40
MST10A5	10 (3)	5	66.4	200	78	86	78.2	40
MST15B5	15 (3)	7.5	95.2	200	86	117	106	54
MST15B6	15 (3)	7.5	95.2	240	86	117	106	54
MST15A4	15 (3)	5	99.6	120	80	128	116.3	59
MST15A5	15 (3)	5	99.6	200	80	128	116.3	59
MST15A6	15 (3)	5	99.6	240	80	128	116.3	59
MST20B5	20 (3)	10	126.4	200	88	161	146	74
MST20B6	20 (3)	10	126.4	240	88	161	146	74
Triplex Expandable To Quadplex
MST05A4-EX4	5 (3) / 5 (4)	5	33.2	120	77	58	52.8	27.3
MST0755-EX4	7.5 (3) / 7.5 (4)	7.5	47.6	200	77	60	54	28
MST10A5–EX4	10 (3) / 10 (4)	5	66.4	200	80	114	103.6	52.6
MST10A6-EX4	10 (3) / 10 (4)	5	66.4	240	80	114	103.6	52.6
MST10B5-EX4	10 (3) / 10 (4)	10	63.2	200	79	82	74	38
MST10B6-EX4	10 (3) / 10 (4)	10	63.2	240	79	82	74	38
MST15A5–EX4	15 (3) / 15 (4)	5	99.6	200	82	170	154.4	78
Sistemas Quadplex
MSQ05A4	50	5	49.8	120	77	58	52.8	27.3
MSQ0755	7.5 (4)	7.5	71.4	200	79	79	71	37
MSQ10B5	10 (4)	10	94.8	200	81	108	98	50
MSQ10A5	10 (4)	5	99.6	200	80	114	103.6	52.6
MSQ10A6	10 (4)	5	99.6	240	80	114	103.6	52.6
MSQ15B5	15 (4)	7.5	142.8	200	81.5	156	140	71
MSQ15B6	15 (4)	7.5	142.8	240	81.5	156	140	71
MSQ15A5	15 (4)	5	149.4	200	82	170	154.4	78
MSQ15A6	15 (4)	5	149.4	240	82	170	154.4	78
MSQ20B5	20 (4)	10	189.6	200	83	214	194	98
MSQ20B6	20 (4)	10	189.6	240	83	214	194	98
Quadplex Expandable to Pentaplex
MSQ15A6-EX5	15 (4) / 15 (5)	5	149.4	240	83	212	192.5	97
Pentaplex Systems
MSP15A5	15 (5)	5	199.2	200	83	212	192.5	97
MSP15A6	15 (5)	5	199.2	240	83	212	192.5	97
MSP15B5	15 (5)	7.5	190.4	200	92	194	175	89
Hexaplex Systems
MSH05A4	5 (6)	5	83	120	78	86	78.2	40
MSH05A5	5 (6)	5	83	200	78	86	78.2	40
MSH10A6	10 (6)	5	166	240	82	170	154.4	78
MSH10B6	10 (6)	10	158	240	93	161	146	74
MSH15A5	15 (6)	5	249	200	84	254	230.6	115.9
MSH15A6	15 (6)	5	249	240	84	254	230.6	115.9
Octoplex Systems
MSO10B6	10 (8)	10	221.2	240	95	214	194	98
Nonaplex Systems
MSN05A5	5 (9)	5	132.8	200	80	128	116.3	59

TECNOLOGÍA DE BOMBA SCROLL SIN ACEITE

Nuestra innovadora tecnología scroll es totalmente exenta de aceite, extremadamente silenciosa y energéticamente eficiente. La bomba scroll tiene pocas piezas móviles, lo que la hace fiable y más fácil de mantener. Los sellos de punta autolubricantes y la ausencia de caja de engranajes hacen que la bomba sea realmente 100% exenta de aceite. Como líderes en tecnología de bombas scroll, nuestro último diseño incorpora varias características innovadoras:

Los cojinetes principales se alojan en hierro fundido duradero en lugar de aluminio, lo que evita el desgaste y el fallo prematuro de la pista del cojinete. Esta bomba puede funcionar al 100% de su capacidad con total confianza.
La función patentada de reengrase de cojinetes se ha mejorado para permitir el mantenimiento desde la parte frontal de la bomba, reduciendo el tiempo de servicio a la mitad.
The patented tip seal design yields the highest flow rates and longevity of any other dry scroll compressor.
La mejora de la eficiencia y la refrigeración se traduce en temperaturas de funcionamiento más bajas.
Extremely low vibration.
Industry first 10hp scroll pump improves system efficiency by producing more output using fewer pumps.

BEST-IN-CLASS FOOTPRINT

Our newly redesigned and upgraded space-saving scroll compressors feature the smallest available footprint on the market, allowing for flexibility of hospital design and ease of installation.

Up to 39% less footprint than leading competitor
Systems designed to fit through 36” door

EASILY SERVICEABLE

Our compressors are low maintenance, energy efficient, and easily serviceable.

Patented Service Slide
Common service items easily accesible
Basemount extends 20” from rack

ENERGY EFFICIENCY

With the Powerex Variable Pump Drive system, each compressor pump is automatically staged on/off individually based on actual system demand, maximizing energy efficiency at all usage levels. Lead compressor status will alternate every time a pump is called for – or every 10 minutes, whichever comes first – which maintains equal run hours and extends maintenance intervals.
Redundancy is built into our system with our multiple pump design, eliminating the need to purchase an additional compressor.

SYSTEM FEATURES

ASME receiver
UL508A control panel
Air purification system
Carbon monoxide monitor
Dew point monitor
All interconnecting piping and wiring
Vibration isolation pads and flex connectors
Most of our multiplex scroll packages now OSHPD certified

Standard Premium Control Panel

PLC controller and 6″ color HMI (Human Machine Interface) touch screen displays the operating status of the unit
UL508A listed and labeled, NEMA 4/12 enclosure
Visual and audible alarms for:
- System overload trip
- High temperature conditions
- Service intervals
- High dew point and CO levels
Panel door includes:
- Visual and audible alarms
- HOA switch for each pump
- 3-position dryer switch
Integrated dew point and carbon monoxide monitors
Building automation gateway with BacNet® protocol
Email notifications for alarms and service alerts

Optional Non-HMI Control Panel

UL508A listed and labeled, NEMA 4/12 enclosure
Timed lead/lag compressor alternation
Visual and audible reserve compressor in use alarm
Redundant control circuit transformers
Dry contacts for remote alarm monitoring
Each compressor provided with:
- Hand/Off/Auto selector switch
- Magnetic starter with 3 leg overload protection
- Visual and audible high temperature shut down
- Hour meter
- Compressor run light
Dew point monitor with LCD dew point display
Carbon monoxide monitor with LCD display of CO concentrations
